| PARAMETERS | VALUES | |
|---|---|---|
| DIAMETER | 63mm | |
| LENGTH | 1000mm | |
| BUBBLE SIZE | 1mm To 3mm | |
| MATERIAL | Membrane | EPDM |
| Support Pipe | PVC | |
| End clamp | SS -304 | |
| AIR FLOW | 2-10 m3/hr | |
| DIFFUSERS SURFACE AREA | 0.21 SqM | |
| EFFECTIVE SURFACE AREA | 0.18 SqM | |
| SEPARATION B/W DIFFUSERS | 0.6 m | |
| END CONNECTION | 3/4 “ BSP | |
